Transport Boxes

Used for transporting samples between different UHV systems in ultra high vacuum conditions.

Manufacturer

Prevac

Prevac are a world leader in the design and production of analytical and deposit scientific and research equipment. Their systems operate in a high and ultra high vacuum environment. They design and construct UHV and HV systems fully adapted to the individual requirements of research projects and industrial applications.

Description

Sample holders/samples can be stored and transported inside the transport box while maintaining UHV conditions. The vacuum is ensured by an ion pump and can be (optionally) monitored by the appropriate pressure gauge. The pump is designed so that it can be powered from a car battery or other power source.

Technical data

for PTS sample holders for flag style sample holders
Weight ≈ 7 kg (8 kg with power supply) ≈ 13.5 kg (14.5 kg with power supply),
depend on transferring length
Pressure range (with pump) down to 1×10-9mbar down to 1×10-10mbar
Mounting flange (transferring port) PTS dedicated load lock connection port DN 40CF
Max. tranfer length 130 – 224 mm (other on request)
Storage up to 2 sample holders for 3 or 6 sample holders

Downloads

Brochures

Transport Box Brochure

View Brochure

Manipulators and Transferring Systems Brochure

View Brochure

Options

Pumping options:

  • NEG Getter pump
    – Pumping speed: 200 l/s
    – Mounting flange: DN 40CF
  • Ion pump
    – Pumping speed: 3 l/s
    – Mounting flange: DN 16CF

Custom designs are available:

  • Various types of sample holders – bespoke transport box designs to accommodate various types and styles of sample holders,
  • Portable infrared chamber – compact and simple design vacuum box dedicated for FTIR spectroscopy investigations. Easy connection to IR spectrometer thanks to its portability.
