The LC-4 Ultra Compact Low Frequency Vibration Isolator
Low frequency vibration isolator for weight loads from 15 to 130 lbs. and 1/2 Hz performance vertical and horizontal.
Key Features
- Available in two configurations, our low horizontal frequency performance of 1.5 Hz or our ultra low performance of 0.5 Hz
- The isolators can be combined into multi isolator systems to support heavier payloads while taking up very little room themselves
- Manually-adjustable
- No Air or Electricity Required
- Can be customised to achieve user specific needs
Manufacturer
Minus K Technology
The Minus K® products, formerly sold under the trade name Nano-K®, represent an important enabling technology. By reducing building and floor vibrations to unprecedented levels, these systems enable vibration sensitive instruments and equipment to perform at unprecedented levels. They are used in a broad spectrum of applications including nanotechnology, biological sciences, semiconductors, materials research, zero-g simulation of spacecraft, and high-end audio. Minus K® is an OEM supplier to leading manufactures of scanning probe microscopes, micro-hardness testers and other vibration-sensitive instruments and equipment. Minus K® customers include private companies and more than 300 leading universities and government laboratories in 51 countries.
Performance
- Vertical natural frequency of 1/2 Hz or less can be achieved over the entire load range.
- Horizontal natural frequency is load dependent. 1 1/2 Hz (low horiz. freq.) or 1/2 Hz (ultra low horiz. freq.) or less natural frequencies can be achieved at or near the nominal load.
| Approximate payload weight range | |
|---|---|
| *Contact us for custom payload ranges | |
| Model | Payload Range* |
| 25LC-4 | 10 - 28 lb (4.5 - 12.7 kg) |
| 35LC-4 | 29 - 40 lb (13.2 - 18.2 kg) |
| 50LC-4 | 38 - 65 lb (17.3 - 29.5 kg) |
| 70LC-4 | 48 - 75 lb (21.8 - 34 kg) |
| 100LC-4 | 75 - 100 lb (34 - 45.3 kg) |
| 125LC-4 | 95 - 130 lb (43 - 59 kg) |
Specifications
| Weight | Approx. 7 lb (3.1 kg) |
| Dimensions (LC-4) |
4.75" W x 4.75" D x 7" H (121mm W x 121mm D x 178mm H) |
| Dimensions (LC-4U) |
4.75" W x 4.75" D x 8" H (121mm W x 121mm D x 203mm H) |
