EM Pro
For labs handling high volumes of tissue specimen embedding, the EM Pro is the ultimate productivity tool.
Manufacturer
RMC Boeckeler
Boeckeler Instruments engineers sample preparation equipment for nanoscale research, under the RMC Boeckeler product line. Their solutions are employed in both life sciences and materials research, with special emphasis in sample preparation for 3D electron microscopy.
EM Pro
Key Features
- Easy touchscreen programming: Integrated 7-inch HD touchscreen with 4 memory presets and the ability to store over 100 unique programs
- Sealed system with active exhaust: Vial caps prevent the escaping and gradual depletion of chemical volume
- Economical! Only small volumes of reagents are needed for each vial
- Programmable agitation: Set the frequency which best meets your sample requirements
- Complete with two specimen holder systems
- Small tabletop footprint
- Quick release exhaust hose
Overview
Simply set your desired parameters - time, agitation, and temperature - and let the EM Pro’s advance automated robotic system precisely transfer specimen baskets from one vial to the next. Its sealed system protects your samples throughout the process, ensuring consistency and reliability.
Achieve consistent, reproducible, and hassle-free embedding with the EM Pro!
Supplied With
- Syringe, Luer Lock, 30ml, 5/pkg
- Specimen stack ring, 50/pkg (50 mesh)
- Mesh screen, 50/pkg (50 mesh)
- Perforated basket lid, 100/pkg
- Specimen basket, large, 50/pkg (with three compartments)
- Specimen basket, small, 50/pkg (with four compartments)
- Processing chamber for EM Pro, 10/pkg
- Reagent vials with caps, 20/pkg
- Basket holder
- Specimen loading station
- Top tool stack
- Specimen load / unload
- Retaining clips, 10/pk
- Specimen unload fork
- Specimen stack top
Specifications
| Number of Programs | Over 100 |
| Interface | HD touch screen |
| Specimen Agitation | Specify specimen agitation frequency |
| Specimen Temperature | Peltier controlled (5°C to 40°C) |
| Active Cooling | Heat-sink components with continuous air flow |
| Chemical Containment | Vials are sealed before, during, and after processing steps |
| Specimen Holders | The following types are offered: a) Two sizes of molded plastic baskets: - three specimen compartments per basket - four specimen compartments per basket b) single compartment specimen stack rings for larger samples or groups of specimens |
| Specimen Capacity | 48 specimens in four-compartment baskets or 18 specimens in three-compartment baskets or 12 sample groups or larger specimens in stack ring holders |
| Specimen Drip | After each processing step, the specimens are lightly agitated to remove excess liquid, before they are transferred into the next vial. The vials are sealed before and after the specimens are moved, preventing any drying between steps |
| Chemical Ventilation | Exhaust system continuously expels fumes from the processor. A heavy-duty extension hose allows for operation outside of a fume hood |
| Dimensions | Height: 458mm x Width: 343mm x Depth: 572mm (Height: 18in x Width:13.5in x Depth:22.5in) |
| Voltage | 100/110/120/220/240 volts, 50/60 Hz |
