Argon-2 Gas Management System
Inert’s Argon-2 dual column Gas Management System is perfect for medium throughput or small to mid-size enclosures that require a < 1ppm O2 and H2O inert atmosphere. The free-standing design allows for easy retro-fit of existing glove boxes, simplifying replacement of obsolete control systems with the latest in gas purification technology.
Manufacturer
Inert
Inert design and deliver the most dependable standardised and custom-built atmosphere Glove Boxes, Gas Management Systems, and Solvent Purification Systems at the most competitive prices. They also offer a full inventory of replacement parts and supplies. Since 1981, they have been the glove box and solvent system design/manufacturer who puts quality, flexibility, and customer service first. As a result, their solutions and after-sales support are unmatched.
Key Features
- High-capacity purification columns
- 0-60 CFM variable speed blower
- 1.5-inch diameter gas loop
Purity Level
< 1ppm O2 and < 1ppm H2O Purity | |
O2 capacity = | 43 L per purifier column |
H2O capacity = | 1800 g per purifier column |
Purifier Column Valves
Automated purifier column valves | Interlocked with the blower. Blower will not run if the valves fail to open |
Circulation Blower
Variable speed circulation blower | 120 cfm max flow rate blower |
Max flow rate through purifier column | 60 cfm (101 m3/h) |
PLC Control
6″ colour touch screen | |
Trending screen | Pressure, O2 and H2O value is logged for 24 hours |
Pressure Control
Automatic pressure control | (+/- 15 mbar) |
Manual pressure control | Footswitch |
Regeneration Sequence
Automatic blower restart after regeneration |
Purge
Purge valve | O2 level, timer or manually controlled |
Vacuum
Vacuum pump | 10 cfm (17 m3/h) rotary vane pump with oil mist eliminator & oil return kit |
Eco Mode Features
Vacuum pump timer | Shuts pump off for energy reduction |
Automated blower speed control | O2 level adjusts blower speed |
System Gas Requirements
Working gas | 399.995% Ar |
Working gas pressure | 55 psi (3.8 bar) |
Working gas flow rate | 250 l/min |
Regeneration gas | 3-7% H2, balance Ar |
Regeneration gas pressure | 5-7 psi (0.3-0.5 bar) |
Regeneration gas flow rate | 30 l/min |
Specifications
Dual purifier column design allows 24/7 operation | Closed loop recirculation |
Piping and fittings | 304 stainless steel |
Circulation piping | 40 mm diameter with DN 40 ISO-KF flanges for easy connection to customer enclosure |
External dimensions (excluding vacuum pump) | 26″ (660 mm) Wide x 36″ (914 mm) Deep x 32″ (813 mm) High |
External surfaces | RAL 9011 (Graphite Black) |
Options
Analysers
Vacuum pumps
Heating
Small capacity external solvent removal
